Specifications Detail
Display
- Diagonal Size86″
- Panel TypeIPS
- Resolution3,840 x 2,160
- Pixel Pitch (HxV)493.5 x 493.5 mm
- Brightness (Typ)400 nit
- Contrast Ratio1,200:1
- Viewing Angle (H/V)178/178
- Response Time8ms
- Glass Haze25%
- Operation Time Support12/7
Connectivity
- HDMI In2
- Version of HDMI2.1
- Version of HDCP2.1
- USB4
- Audio InStereo Mini Jack
- Audio OutStereo Mini Jack
- Video OutYes
- RS232 InYes
- RJ45 InYes
- WiFiWi-Fi 5: 802.11ac
- BluetoothYes
Power
- Power SupplyAC100-240V 50/60Hz
- Power Consumption (On Mode)493 W
- Power Consumption (Sleep Mode)0.5 W
Dimension
- Set Dimension (WxHxD)1961.8 x 1170 x 87.7 mm
- Package Dimension (WxHxD)2095 x 1265 x 185 mm
Weight
- Set Weight62.5 kg
- Package Weight (kg)74.1 kg
Operation Conditions
- Temperature0 ~ +40℃
- Humidity10 ~ 80%, non-condensing
Mechanical Specification
- VESA Mount800 x 600 mm
- Bezel Width17.2mm
- Bezel ColorBlack
Optional Feature
- TouchYes
SoC
- OS VersionAndroid-14
- Flash Memory Size64GB
Eco
- Energy Efficiency ClassA
Touch
- Touch TechnologyIR
